OilMat™ T2
Mobile fluid management for 200-litre drums..
OilMat™ T2 brings the fluid directly to the vehicle, combining the capacity of a standard 200-litre drum with the flexibility of a mobile dispensing system.
OILMAT™ T2
OilMat™ T2 is a mobile fluid dispensing system designed for standard 200-litre drums. Instead of bringing the vehicle to a fixed dispensing point, T2 brings the fluid directly to the vehicle.
Built on the OilMat™ platform, T2 combines precise dispensing with user and job tracking, reporting and automatic reordering — without fixed piping or compressed air.
With its high-capacity drum format and mobile design, T2 is ideal for workshops with higher fluid consumption that still want the flexibility to move fluids wherever they are needed.
200-litre capacity. Wherever you need it.
High capacity. Built to move.
200-litre drum capacity
Designed around standard 200 L drums, combining high fluid capacity with a fully mobile workshop solution.
Built for higher-flow applications
T2 can be configured with larger hose dimensions for applications requiring higher flow, including truck and heavy-duty workshops.
Cordless operation
Powered by a Milwaukee M12 battery, T2 can be moved and used throughout the workshop without fixed piping, compressed air or a permanent power connection.
Adjustable dispensing speed
Reduce the dispensing speed when required, including for vehicles with restricted or slower oil filling points.
Technical specifications
Max. viscosity
Suction connection
Outlet connection
Operating voltage
Battery socket
Metal
Plastic
Weight
Flow rate
Flow per Ah
250 cSt at 40°C
Push-in, D16 mm
Push-in, D14 mm
12–15 V DC
Milwaukee M12
Grey, RAL 7015 / Galvanised
Black
40 kg
2,5-5 L/min*
Approx. 20 L/Ah*
*5W-30 at 20°C. 5 L/min requires a high-flow configuration. Performance varies with viscosity and temperature.
Accessories
Hose configurations
OilMat™ P is supplied without hoses, allowing the system to be configured for the specific application.
Choose the appropriate suction and outlet hose configuration based on the container setup and required flow.
View all OilMat™ accessories →
Video
See OilMat™ T2 in action
See how OilMat™ T2 brings a 200 L drum directly to the vehicle for precise, controlled dispensing wherever it is needed in the workshop.
See OilMat™ T2 in everyday workshop use, combining mobile dispensing with the capacity of a 200 L drum.
Support & Downloads
Product datasheet
Product information, technical specifications and dimensions for OilMat™ T1.
Technical support
Access manuals, setup guides, troubleshooting and technical support for OilMat™ systems.
